BTE23-13 Microcontroller (Renesas DF2238BTE13)
KSH 600.00
Out of Stock
The BTE2313 is a highperformance 16-bit microcontroller from the Renesas H8S/2000 family, designed for demanding embedded applications [citation:1]. Featuring a 256KB Flash memory, 16KB RAM, and a 13MHz operating speed, this powerful MCU is ideal for motor control, system monitoring, and industrial automation projects.
| Parameter | Value |
|---|---|
| Manufacturer | Renesas Electronics [citation:1] |
| Series | H8S/2200 [citation:2] |
| Core | H8S/2000 16-bit [citation:1] |
| Speed | 13MHz [citation:2] |
| Program Memory | 256KB FLASH [citation:2] |
| RAM | 16KB [citation:3] |
| Supply Voltage | 2.7V - 5.5V [citation:3] |
| Operating Temp | -20°C to +75°C [citation:2] |
| I/O Pins | 72 [citation:2] |
| Package | 100-TQFP (14x14mm) [citation:2] |
| Data Converters | 8x10bit ADC, 2x8bit DAC [citation:2] |
| Peripherals | POR, PWM, WDT [citation:2] |
| Interfaces | I2C, SCI, SmartCard [citation:2] |
| Mounting | Surface Mount [citation:3] |
| Oscillator | Internal [citation:2] |
= Key Features =
Powerful Core 16bit H8S/2000 processor running at 13MHz [citation:1]
Large Memory - 256KB FLASH program memory and 16KB RAM [citation:2]
Rich I/O 72 generalpurpose I/O pins for extensive connectivity [citation:2]
Multiple Interfaces - Supports I2C, SCI, and SmartCard communication [citation:2]
OnChip Converters 8channel 10bit ADC and 2channel 8bit DAC [citation:2]
Integrated Peripherals - POR, PWM, WDT for system control [citation:2]
Wide Voltage Range - 2.7V to 5.5V operation [citation:3]
Surface Mount 100pin TQFP package (14x14mm) for compact design [citation:2]
√ Compatible with I2C, SCI, and SmartCard interfaces [citation:2]
√ Built-in ADC and DAC for analog applications [citation:2]
√ Power-on reset and watchdog timer for system safety [citation:2]
√ Internal oscillator for reduced external components [citation:2]
√ Reliable and well-documented Renesas architecture
The Renesas BTE2313 (DF2238BTE13) delivers powerful 16bit performance, extensive memory, and rich peripheral integration for demanding industrial and automotive embedded applications. A trusted choice for robust system control.
