Arduino Super Mini Nano V3 Atmega328P Microcontroller Core Board Soldering Development Board Improved Version Module

SKU: HMJ136 Category: Microcontrollers
KSH 900.00
In Stock

Product Description

Arduino Super Mini Nano V3 ATmega328P Development Board

Compact Improved Version Microcontroller Core Module

This Super Mini Nano V3 board is a compact, breadboardfriendly development board based on the ATmega328P microcontroller [citation:7][citation:8]. It delivers the same powerful functionality as the larger Arduino boards in a spacesaving design, ideal for embedding in projects or prototyping on a breadboard [citation:2][citation:3].

Compact and BreadboardFriendly Ideal for space-constrained projects and permanent embedding.
ATmega328P Core Reliable 8bit AVR microcontroller running at 16MHz.
Board features a CH340G USBtoserial chip for easy programming and communication [citation:1][citation:5][citation:8].
Select "Arduino Nano" board and "ATmega328P" processor in the Arduino IDE [citation:5][citation:8].
I/O pins operate at 5V logic level - use level shifters for 3.3V devices.

Technical Specifications

ParameterValue
MicrocontrollerATmega328P
Clock Speed16MHz [citation:5][citation:7]
Operating Voltage5V [citation:3][citation:7]
Input Voltage (recommended)7-12V [citation:3][citation:7]
Digital I/O Pins14 (6 with PWM) [citation:1][citation:5]
Analog Input Pins8 (A0-A7) [citation:1][citation:8]
Flash Memory32KB (2KB bootloader) [citation:1][citation:3]
SRAM2KB [citation:1][citation:5]
EEPROM1KB [citation:1][citation:5]
DC Current per I/O Pin40mA [citation:1][citation:3]

= Key Features =

+Super Mini Footprint - Significantly smaller than standard Nano boards [citation:5].

+Improved USB Chip - Uses CH340G for better compatibility and stability [citation:8][citation:10].

+USBC Connectivity Modern reversible connector option available on many super mini versions [citation:1][citation:5][citation:9].

+BreadboardFriendly Standard 2.54mm pin spacing for easy prototyping [citation:8][citation:11].

+8 Analog Inputs Includes two extra analogonly pins (A6 and A7) [citation:8].

= Applications =

  1. Compact Arduino prototyping
  2. Wearable electronics
  3. Robotics and automation
  4. Sensor data acquisition
  5. Permanent project embedding
Full Arduino Compatibility - Works with standard libraries and sketches [citation:2][citation:8].
Versatile Power Options USB, 5V pin, or 712V via VIN [citation:2][citation:3].

√ ATmega328P with Arduino bootloader pre-installed [citation:1].

√ Includes pin headers (soldered or unsoldered depending on version).

√ Popular platform with extensive community support.

Troubleshooting

Board not detected:

  • Install CH340G USB driver if not automatically recognized [citation:2][citation:6].
  • Use a data-capable USB cable (not just charging cable) [citation:5].
  • Try a different USB port.

Upload fails:

  • Select Tools → Board → Arduino Nano.
  • Select Tools → Processor → ATmega328P (or Old Bootloader for some clones) [citation:5][citation:8].
  • Check correct COM port selection.
