NRF24L01 Wireless adapter Module 3.3V New Socket Adapter plate Board 8Pin For arduino Robot Car 24L01 Wireless Module

SKU: HMJ768 Category: Connectors
KSH 500.00
Out of Stock

Product Description

NRF24L01 Wireless Adapter Module 3.3V 8-Pin Socket Board

PlugandPlay Adapter for Arduino Robot Car Wireless Modules

This NRF24L01 adapter board provides a convenient 8-pin socket for connecting NRF24L01 wireless modules to Arduino projects. It simplifies wiring for robot car and wireless communication systems.

Easy Connection 8pin socket eliminates messy wiring
3.3V Regulation - Onboard regulator for stable power
Use with 3.3V or 5V Arduino boards
Verify pin orientation before inserting module
Do not insert module backward

Technical Specifications

ParameterValue
Connector Type8-pin socket
Voltage Input3.3V to 5V
Onboard Regulator3.3V output
CompatibilityNRF24L01, NRF24L01+
Pin Header2.54mm pitch
PCB Size28mm x 20mm

= Key Features =

Standardized Pins - Power, ground, SPI, and CE/CSN

Onboard LED - Power indicator

Shield Compatible - Fits Arduino boards directly

Labeled Pins - Easy identification

Dual Power Option - Uses onboard regulator or external 3.3V

= Applications =

  1. Arduino robot car wireless control
  2. Remote control systems
  3. Wireless sensor networks
  4. IoT communication links
  5. Multi-node wireless projects
PlugandPlay - No soldering required
Saves Time - Clean and organized wiring

√ Stackable design

√ Breakout pins for external access

√ Works with all NRF24L01 variants

Pin Mapping

Adapter pins:

  • VCC: 3.3V power output
  • GND: Ground
  • CE: Chip Enable
  • CSN: Chip Select
  • SCK: SPI Clock
  • MOSI: SPI Data In
  • MISO: SPI Data Out
  • IRQ: Interrupt output

Direct Arduino Wiring - Standard SPI pins

Labeled Clearly - No guessing connections

Works with Uno, Nano, Mega
Compatible with most NRF libraries

√ Pre-assembled and tested

√ No extra components needed

√ 3.3V regulator onboard

Connection Guide

To Arduino Uno/Nano:

  • VCC: 5V or 3.3V
  • GND: GND
  • CE: Pin 9
  • CSN: Pin 10
  • SCK: Pin 13
  • MOSI: Pin 11
  • MISO: Pin 12

To Arduino Mega:

  • Same but SPI pins differ
  • SCK52, MOSI51, MISO=50
Use 5V for onboard regulator, 3.3V for bypass
Cut regulator jumper for external 3.3V use
Do not use 5V directly on NRF module
Ensure regulator can supply 150mA

Troubleshooting

Module not detected:

  • Check power supply
  • Verify SPI connections
  • Avoid loose pins

Wireless not working:

  • Check CE and CSN pins
  • Verify both modules same channel
  • Avoid interference
