BPW34 Photodiode

SKU: HMJ508 Category: Intergrated circuits
KSH 100.00
In Stock

Product Description

BPW34 Silicon PIN Photodiode

High-Speed Light and Infrared Sensor for Arduino and DIY Projects

The BPW34 is a highspeed, generalpurpose PIN photodiode from Vishay. Its fast response time and sensitivity to visible and near-infrared light make it a popular choice for remote controls, light detection, and even creative DIY projects like shutter speed timers or radiation detectors [citation:1][citation:4][citation:7].

HighSpeed Detection 100ns rise/fall time allows for fast light pulse detection [citation:1][citation:9]
Wide Spectral Sensitivity - Detects light from 430nm to 1100nm, covering both visible and IR ranges [citation:9]
Operating temperature range is -40°C to +100°C [citation:1][citation:5].
The BPW34 can be used in photovoltaic mode (like a solar cell) or photoconductive mode (faster response) [citation:4][citation:6].
The component is sensitive to a wide range of light. To detect only specific wavelengths, a filter may be required [citation:12].

Technical Specifications

ParameterValue
:-:-
Wavelength Range430nm to 1100nm [citation:9]
Peak Sensitivity900nm [citation:1][citation:5]
Radiant Sensitive Area7.5mm² [citation:1][citation:9]
Switching Speed (Rise/Fall)100ns (typ.) [citation:1][citation:9]
Dark Current2nA (typ.) [citation:1][citation:5]
Open Circuit Voltage350mV (typ.) [citation:10]
PackageDIP (Through-hole, clear plastic) [citation:1][citation:10]

= Key Features =

High Radiant Sensitivity - Detects low light levels effectively [citation:1][citation:5].

Miniature, Flat Package - Fits easily into compact designs and breadboards [citation:1][citation:4].

Fast Response Times Ideal for applications involving highspeed light pulses and data transmission [citation:1][citation:10].

Sensitive to Visible & NIR - Versatile for use in IR remote controls, ambient light sensors, and more [citation:1][citation:4].

= Applications =

  1. IR remote control receivers for TVs, hi-fi, and dimmers [citation:4][citation:8].
  2. Photointerrupters and industrial control systems [citation:4][citation:8].
  3. DIY light detection projects, such as shutter speed timers or light meters [citation:3][citation:6].
  4. High-speed photo detectors in data communication [citation:4][citation:10].
Versatile Performance - A flexible component suitable for many sensing projects
LongStanding Standard A reliable and well-documented industry staple

√ DIP package is compatible with standard 2.54mm breadboards and perfboards

√ Sensitive to both visible and IR light
