ATTINY85-20PU DIP-8 IC MCU

SKU: HMJ147 Category: Intergrated circuits
KSH 700.00
In Stock

Product Description

ATTINY8520PU 8bit AVR Microcontroller in DIP-8

Compact and Low-Power MCU for Embedded Projects

The ATTINY8520PU is a highperformance, lowpower 8bit AVR RISCbased microcontroller from Microchip (formerly Atmel), housed in an 8pin DIP package for easy breadboard and through-hole prototyping [citation:1][citation:6].

8KB Flash & 20MHz Speed Offers a balanced combination of program memory and processing power for smallscale projects.
8pin PDIP Package Breadboardfriendly with throughhole mounting [citation:1][citation:4].
Operating voltage: 2.7V to 5.5V.
Industrial temperature range: -40°C to +85°C.
6 generalpurpose I/O lines and 4channel 10-bit ADC [citation:1][citation:7].
Requires an external programmer (e.g., USBasp) for programming. Supports Arduino IDE with appropriate core [citation:4].

Technical Specifications

ParameterValue
CoreAVR 8-bit RISC [citation:1][citation:7]
Max Clock Speed20MHz [citation:1][citation:4]
Flash Memory8KB [citation:1][citation:4]
EEPROM512 bytes [citation:1][citation:4]
SRAM512 bytes [citation:1][citation:4]
GPIO6 I/O lines [citation:1][citation:4]
ADC4 channels, 10-bit [citation:1][citation:4]
Package8-pin PDIP [citation:1][citation:4]
Supply Voltage2.7V - 5.5V [citation:1][citation:4]

= Key Features =

+Advanced RISC Architecture 120 instructions, most singleclock execution [citation:3][citation:9].

+Integrated Peripherals 8bit and highspeed 8bit timers, USI for SPI/I2C, PWM, watchdog timer [citation:1][citation:3].

+debugWIRE Interface Onchip debugging [citation:1][citation:5].

+Low Power Consumption Idle, ADC noise reduction, and powerdown modes for battery-powered applications [citation:3][citation:4].

= Applications =

  1. Wearable technology and IoT devices [citation:4][citation:12].
  2. Sensors and monitoring systems [citation:4][citation:12].
  3. LED lighting control [citation:4].
  4. Home automation projects and robotics [citation:4][citation:7].
  5. Small-scale embedded systems and DIY electronics [citation:4][citation:7].
Popular Choice Wellsuited for compact and cost-effective embedded designs [citation:4].
Arduino IDE Compatible - Easily programmable for rapid prototyping [citation:4][citation:11].

√ Available in PDIP8 for breadboardfriendly development.

√ Supports SPI and I2C communication via USI interface.
