12V NKP Small Self-priming Mini Circulation Micro Pumping Peristaltic Pump 5W Silicone Tube

SKU: HMJ552 Category: Actuators
KSH 1,500.00
Out of Stock

Product Description

12V NKP Mini Self-priming Peristaltic Pump (5W, Silicone Tube)

Compact DC Peristaltic Pump for Precise Liquid Transfer

This NKP series micro peristaltic pump uses a rotating roller to squeeze a silicone tube, moving liquids without any contact between the pump mechanism and the fluid [citation:5][citation:9]. It is self-priming and can run dry without damage, making it suitable for applications like water sampling, dosing, and ink circulation [citation:4][citation:9].

SelfPriming & Fluid Isolation The pump can self-prime and the fluid only touches the silicone tubing, preventing contamination [citation:4][citation:9].
Compact & Low Power - Consumes only 5W and has a small footprint, making it suitable for portable and embedded projects [citation:2][citation:6].
Operating Voltage: 12V DC (also compatible with 6V-24V depending on the specific model) [citation:2][citation:3][citation:6].
Flow Rate: 10 to 60+ ml/min depending on the motor and tubing size (e.g., S04 tubing gives 10ml/min, S08 tubing provides 60ml/min) [citation:2][citation:5][citation:6].
Typical Current: Around 0.25A [citation:7][citation:10].
The pump typically uses 3 rotors to minimize pulsation in the flow [citation:4][citation:8].

Technical Specifications (Varies by Model)

ParameterValue
:-:-
*Power*5W [citation:2][citation:5][citation:6]
*Voltage Options*6V, 12V, or 24V DC [citation:10][citation:4]
*Flow Rate (at 12V)*≥10 ml/min to ≥60 ml/min [citation:2][citation:5][citation:6]
*Motor Type*DC Brushed Motor [citation:2][citation:4][citation:10]
*Tube Material*Silicone (S) or BPT [citation:4][citation:10]
*Tube Sizes*04 (1x3mm), 06 (2x4mm), 08# (2.5x4.5mm) [citation:2][citation:4][citation:6]
*Pump Tube Life*200 hours (Silicone) [citation:2][citation:6][citation:10]
*Motor Life*800 hours [citation:2][citation:6][citation:10]

= Applications =

  1. Peristaltic pumps are widely used in applications requiring sterile or precise fluid handling, such as laboratory dosing and medical devices [citation:7][citation:9].
  2. They are commonly used in aquariums, water circulation systems, and inkjet printers [citation:3][citation:8].
  3. The pump can be controlled via a simple power switch or with a PWM signal for speed regulation [citation:5]. It is also compatible with Arduino and Raspberry Pi projects [citation:9].
The silicone tube can be easily replaced, extending the pump's usable life [citation:4].

√ Tube replacement is simple and quick.

√ Forward and reverse rotation is possible by reversing the DC polarity [citation:4][citation:12].
