W25Q64 64Mbit FLASH storage Module SPI Interface BV FV

SKU: HMJ549 Category: Memory cards and usb flash
KSH 550.00
Out of Stock

Product Description

W25Q64 64Mbit SPI Flash Storage Module

High-Speed Serial Flash Memory for Microcontroller Projects

The W25Q64 is a 64Mbit (8Mbyte) serial NOR Flash memory module designed for reliable data storage and code execution [citation:2][citation:5]. It is widely used for firmware storage, data logging, and voice/text storage in embedded systems [citation:6].

64Mbit Storage Capacity Provides 8MB of nonvolatile memory for your projects
HighSpeed SPI Interface Supports up to 133MHz clock with Quad SPI mode
Operating voltage: 2.7V to 3.6V [citation:2][citation:6]
Memory organization: 32,768 pages of 256 bytes each [citation:3][citation:6]
More than 100,000 erase/program cycles [citation:6]
More than 20-year data retention [citation:6]

Key Features

+Supports Standard, Dual, and Quad SPI for flexible interface options [citation:2][citation:3]

+Uniform 4KB sectors and 32KB/64KB blocks for efficient erase operations [citation:2][citation:6]

+Low power consumption: 4mA active read current, 1µA power-down current [citation:2][citation:3]

+Hardware and software write protection features [citation:3][citation:6]

+64-bit unique ID and JEDEC standard manufacturer/device ID [citation:3][citation:6]

= Applications =

  1. Code shadowing and executeinplace (XIP) for microcontrollers [citation:5][citation:6]
  2. Data logging, voice, and text storage [citation:5][citation:6]
  3. Firmware storage and system configuration [citation:6]
  4. IoT devices and industrial control systems [citation:6]
Reliable Storage Solution - Proven SpiFlash technology from Winbond
Easy Integration - SPI interface works with Arduino, STM32, ESP32

√ 64Mbit (8MB) capacity for moderate storage needs

√ Available in SOIC8, WSON8, and other packages [citation:6][citation:9]

√ Compatible with 3.3V logic systems [citation:2][citation:6]

Hardware Interface

PinFunctionArduino Connection
CSChip SelectDigital Pin 10 (example)
CLKSerial ClockPin 13 (SCK)
DI (MOSI)Data InputPin 11 (MOSI)
DO (MISO)Data OutputPin 12 (MISO)
VCCPower (2.7-3.6V)3.3V
GNDGroundGND

> Use the SPIMemory library in Arduino IDE for easy interfacing [citation:4][citation:8]

For 5V systems, use a module with onboard level shifting [citation:11][citation:12]
Chips come blank and do not have a wear-leveling subsystem [citation:11][citation:12]

Troubleshooting

Module not detected:

  • Verify VCC is within 2.7-3.6V range
  • Check SPI connections (MISO, MOSI, SCK, CS)
  • Ensure CS pin is pulled LOW to start transaction

No data read/write:

  • Use 3.3V logic level for direct connection
  • For 5V systems, use a level shifter module [citation:11][citation:12]
  • Verify library initialization and SPI settings
