Electromagnet P20/15 Cylinder Electric Magnet DC 6VSuction 3KG 30N Strong Electromagnet Solenoid
KSH 700.00
Out of Stock
The P20/15 Cylinder Electromagnet is a compact, highpower solenoid that generates a powerful 3KG (30N) suction force when energized with 6V DC. Perfect for batterypowered robotics, automation, and electronic locking systems, it provides instant magnetic force only when power is applied. The electromagnet automatically demagnetizes when power is removed.
| Parameter | Value |
|---|---|
| Model | KKP20/15 / ELEP20/15 |
| Supply Voltage | DC 6V |
| Power Consumption | 2W - 2.5W |
| Current Draw | 0.3A - 0.4A |
| Suction Force | 3KG / 30N |
| Dimensions | 20mm (D) x 15mm (L) |
| Core Diameter | 8mm |
| Mounting Thread | M4 x 10mm |
| Lead Wire Length | ~30cm |
| Body Material | Mild Steel / Iron |
| Operating Temp | -20°C to 130°C |
| Weight | ~26g |
= Key Features =
Strong Suction - 3KG (30N) holding force for reliable operation
Compact Design - Small 20x15mm form factor fits tight spaces
Instant On/Off - Magnetic only when powered, no residual magnetism
Low Power Only 22.5W consumption for efficient operation
Easy Mounting Prethreaded M4 rear hole for secure installation
High Temperature - Operates reliably up to 130°C
Durable Construction - Quality materials for long service life
Low Voltage 6V operation ideal for batterypowered projects
| Wire | Connection | Description |
|---|---|---|
| Red | VCC (6V DC) | Positive power input |
| Black | GND | Ground connection |
> Connect to 6V DC power supply with sufficient current (min. 0.5A)
When using with Arduino or microcontroller, connect a flyback diode across the electromagnet:
6V+ ──────┤|────── Electromagnet ────── GND
Diode
(Cathode toward 6V+)
√ Works with 6V power supplies and batteries
√ Pre-wired leads for easy connection
√ Durable steel construction
√ No moving parts - long service life
√ Reliable and repeatable performance
√ Great value for automation projects
The P20/15 Cylinder Electromagnet delivers powerful, reliable magnetic force in a compact package for 6V systems. Perfect for battery-powered robotics, automation, and DIY projects requiring controllable suction.
