7x15 cm Stripboard (Veroboard)

Prototyping with Stripboard for Electronics Projects

Features

• Standard 7x15 cm Stripboard used for breadboarding and prototyping.
• Pre-drilled holes with copper pads for easy component placement and soldering.
• Ideal for creating quick prototypes of electronic circuits without the need for PCB manufacturing.
• Compatible with standard 0.1-inch (2.54 mm) spaced components like resistors, capacitors, and ICs.
• Flexible and easy to cut to smaller sizes as per project requirements.

Specifications

Parameter	Specification
Board Dimensions	7 cm x 15 cm
Hole Pitch	2.54 mm (0.1 inch)
Material	Fiberboard with copper traces
Copper Pad Thickness	Approximately 0.3 mm
Weight	Approximately 10 g
Thickness	1.6 mm (standard PCB thickness)

Applications

• Ideal for building temporary or permanent electronic prototypes.
• Used in electronics workshops and educational settings for learning circuit design.
• Perfect for developing custom circuits and breadboarding small devices.
• Used in DIY projects, especially for hobbyists and makers.
• Commonly employed in robotics, automation, and home automation projects.

Benefits

• Provides an easy and cost-effective way to build and test circuits.
• No need for specialized PCB manufacturing or etching processes.
• Customizable size and shape based on project needs.
• Allows for quick prototyping and circuit modifications without the need for soldering to a PCB.
• Reusable for multiple projects and circuit designs.

How It Works

The **7x15 cm Stripboard** is a pre-drilled board used for connecting electronic components via soldering. The copper traces on the board provide electrical connectivity between components, and the holes allow for the easy insertion of component leads. When building a circuit, components are placed over the holes and connected with solder. The copper traces are often cut or modified using a wire cutter to create custom connections between different components, making it an ideal solution for rapid prototyping and testing.

Maintenance Tips

• Store in a dry environment to prevent oxidation of the copper pads.
• Clean the board with isopropyl alcohol to remove any flux residue after soldering.
• Avoid excessive heat during soldering to prevent damage to the copper pads.
• Use fine gauge wire or copper tracks for clean and neat soldering.
• Ensure that the copper pads are intact before using the board for another circuit.
